240W power supply (100-240VAC / 24V/10A DC), overvoltage, overload and thermal protection, DIN mounting, warranty 54 months

icon-sku SKU: AS10PWR24024

Available in 24h icon-available
Add to Compare
67,00 EUR
Courier delivery - from 9 EUR   own transport - free of charge   Conditions of delivery »
The product has technical support by ASTRAADA  Support details »


Product description

AS10PWR24024 switching power supplies are designed for industrial applications. They provide 24VDC output voltage and 240W output power. Thanks to their parameters, they are suitable for operation in harsh environmental conditions. The power supplies meet relevant safety standards and have a number of safety features. Astraada Power switching power supplies are suitable for DIN rail mounting.

Parameters

AS10PWR24024 power supply

Input voltage 85 ÷ 264 VAC
Nominal power 240 W
Output voltage 24 VDC
(22 ÷ 28 VDC)
Output current 0 ÷ 10 A
Overload protection 105 ÷ 150%
Overvoltage protection 115 ÷ 135%
Reset Automatic resumption
EMC standards EN55022 class B;
EN61000-3-2,3;
EN61000-6-2;
EN61000-6-2;
EN61000-4-2,3,4,5,6,8,11;
ENV50204
Dimensions (width x height x depth) [mm] 60.0 x 123.6
x 117.6 mm
Weight 0.8 kg
Operating temperature range -20 ÷ +70°C
Humidity (non-condensing) 5 ÷ 95%
